KKK-A-1822 E
TYPE II
FIGURE 2
Standard Van,
Integral Cab-Body Ambulance
For vehicles of 203 cm
AMBULANCE TYPE II
(80 in.) or more overall
FMVSS NO. 108
width.
1.
Headlamp, (2) white (4 white optional)
Recommended lamp and
* 2.
Front side marker lamp, (2) amber
refelctor location in
3.
Front side reflector, (2) amber
accordance with the
4.
Front turn signal, (2) amber, (includes vehicular
Federal Motor Vehicle
hazard warning signal flahser)
Safety Standard No. 108
and Federal Ambulance
5.
Rear side marker lamp, (2) red
Specification KKK-A-
6.
Rear side reflector, (2) red
1822.
7.
Rear relfector, (2) red
8.
Rear stop, tail & turn signal lamp, (2) red, (turn
NOTE:
signal section may be amber, includes
Lamps and reflectors
vehicular hazard warning signal flasher)
may be mounted at other
9.
Rear backup lamp, (1) white
practical locations pro-
10. Rear license plate lamp, (1) white
vided location and vis-
ibility requirements of
11. Front warning light, (2) red
Federal Motor Vehicle
11a. Front warning light, (1) white
Safety Standard No. 108
12. Rear warning light, (2) red
and Federal Ambulance
Specification KKK-A-
12a. Rear warning light, (1) amber
1822 are met. (Drawings
13. Side warning light, (2) red per side
not to scale.)
14. Grille light, (2) red
15. Intersection lights, (1) red per side
16. Side floodlight, (2) white
16a. Rear floodlight, (1)
17. Spotlight, (white hand held)
18. Spotlight, (white, optional location)
*Flashes with front/rear turn signal & vehicular
hazard warning signal flasher.
