KKK-A-1822 E
TYPE I
FIGURE 1
Conventional, Cab-Chassis
With Modular Ambulance Body
For vehicles of 203 cm
AMBULANCE TYPE 1
(80 in.) or more overall
width.
FMVSS NO. 108
1.
Headlamp, (2) white (4 white optional)
Recommended lamp and
* 2.
Front side marker lamp, (2) amber
refelctor location in
3.
Front side reflector, (2) amber
accordance with the
4.
Front turn signal, (2) amber, (includes vehicular
Federal Motor Vehicle
Safety Standard No. 108
hazard warning signal flahser)
and Federal Ambulance
5.
Front identification lamps, (3) amber
Specification KKK-A-
6.
Front clearance lamp, (2) amber
1822.
* 7.
Rear side marker lamp, (2) red
8.
Rear side reflector, (2) red
NOTE:
9.
Rear identification lamps, (3) red
Lamps and reflectors
10. Rear clearance lamp, (2) red
may be mounted at other
11. Rear relfector, (2) red
practical locations pro-
vided location and vis-
12. Rear, stop, tail, lamp, (2) red
ibility requirements of
12a. Rear turn signal, (2) amber. Includes vehicular
Federal Motor Vehicle
hazard warning signal flasher. (optional location)
Safety Standard No. 108
13. Rear backup lamp, (1) white
and Federal Ambulance
Specification KKK-A-
14. Rear license plate lamp, (1) white
1822 are met. (Drawings
15. Front warning light, (2) red
not to scale.)
15a. Front warning light, (1) white
16. Rear warning light, (2) red
16a. Rear warning light, (1) amber
17. Side warning light, (2) red per side
18. Grille light, (2) red
19. Intersection lights, (1) red per side
20. Side floodlight, (2) white
20a. Rear floodlight, (1) white
21. Spotlight, (white hand held)
21a. Sportlight, (white, optional location)
*Flashes with front/rear turn signal & vehicular
hazard warning signal flasher.
