KKK-A-1822 E
TYPE III
FIGURE 3
Cutaway Van, Cab-Chassis with
Integrated Modular Ambulance Body
For vehicles of 203 cm
(80 in.) or more overall
AMBULANCE TYPE III
width.
FMVSS NO. 108
1.
Headlamp, (2) white (4 white optional)
Recommended lamp and
* 2.
Front side marker lamp, (2) amber
refelctor location in
3.
Front side reflector, (2) amber
accordance with the
Federal Motor Vehicle
4.
Front turn signal, (2) amber, (includes vehicular
Safety Standard No. 108
hazard warning signal flahser)
and Federal Ambulance
5.
Front identification lamps, (3) amber
Specification KKK-A-
6.
Front clearance lamp, (2) amber
1822.
* 7.
Rear side marker lamp, (2) red
8.
Rear side reflector, (2) red
NOTE:
9.
Rear identification lamps, (3) red
Lamps and reflectors
10. Rear clearance lamp, (2) red
may be mounted at other
practical locations pro-
11. Rear relfector, (2) red
vided location and vis-
12. Rear, stop, tail, lamp, (2) red
ibility requirements of
12a. Rear turn signal, (2) amber. (Includes vehicular
Federal Motor Vehicle
hazard warning signal flasher; optional location)
Safety Standard No. 108
and Federal Ambulance
13. Rear backup lamp, (1) white
Specification KKK-A-
14. Rear license plate lamp, (1) white
1822 are met. (Drawings
15. Front warning light, (2) red
not to scale.)
15a. Front warning light, (1) white
16. Rear warning light, (2) red
16a. Rear warning light, (1) amber
17. Side warning light, (2) red per side
18. Grille light, (2) red
19. Intersection lights, (1) red per side
20. Side floodlight, (2) white
20a. Rear floodlight, (1) white
21. Spotlight, (white, hand held)
21a. Sportlight, (white, optional location)
*Flashes with front/rear turn signal & vehicular
hazard warning signal flasher.
92
