KKK-A-1822 E
3.17
UNDERCOATING.
Unless the ambulance is rustproofed, the vehicle shall be undercoated for sound deadening, corrosion,
and stone damage protection. A commercial, sandless, petroleum base undercoating or other materials
providing equivalent protection, shall be applied to the underbody and under chassis sheet metal
surfaces to a thickness of 1.6 mm to 3.2 mm (1/16 to 1/8 in.), except to the drive shafts, drain holes,
lubrication points, engine/transmission oil pans, fuel tanks, heavy castings, suspension components,
heat shields, heat diffusing devices, catalytic converters, and areas 30.5 cm (12 in.) or less from the
exhaust system(s) as well as other areas specifically excluded by the chassis manufacturer. These
areas shall be kept free of coating material. Chassis frame, underside of engine compartment hood,
and underbody surfaces in excess of 3.2 mm (1/8 in.) thickness, or that are inaccessible without
removing vehicle fuel tank(s) or other major components shall not require undercoating.
3.18
RUSTPROOFING
When specified (see 6.2-uu), ambulance shall be rustproofed in accordance with Fed. Std. No. 297.
3.19
MARKINGS, DATA PLATES, WARRANTY NOTICE, ETC.
Unless otherwise specified (see 6.2-vv), final stage manufacturer's caution plates and
identification plates shall be conspicuously installed for all equipment, etc., furnished
requiring such notices. Other than the manufacturer's trademark(s) names, no other
identification than that authoritatively specified shall be shown on exterior of the vehicle.
The ambulance/vehicle manufacturer's "Star of Life" certification shall be provided on a
placard or label as shown below, permanently affixed and easily visible in the ambulance oxygen
compartment (see 4.3).
SAMPLE LABEL
CERTIFIED "STAR OF LIFE" AMBULANCE
MFG
DATE OF
BY _____________________________________ MANUFACTURE MO, YR______
ADDRESS __________________________________________________________
CITY _____________________________________
STATE ___
ZIP ________
This Ambulance conforms to Federal Specification KKK-A-1822 in effect on the date of
manufacture shown above.
AMBULANCE IDENTIFICATION NUMBER
TYPE - CLASS - FLOOR PLAN - SERIAL NO.
CURB WEIGHT
PAYLOAD MAX
GROSS WT. MAX
____________________
__________________
______________________
kg/lbs.
kg/lbs.
kg/lbs.
67
