KKK-A-1822 E
TABLE 1
FLASH PATTERN
MINIMUM FLASH ENERGY, Cd-S PER FLASH, PER FIXTURE
COLOR
RED
CLEAR
AMBER
LOCATION
GRILL & FENDERS
UPPER BODY
FRONT CENTER
REAR CENTER*
CORNERS
DAY
160 Cd-S @ HV
240 Cd-S @ HV
900 Cd-S @ HV
600 Cd-S @ HV
80 Cd-S @ + 50 H
120 Cd-S @ + 50 H
450 Cd-S @ + 50 H
300 Cd-S @ + 50 H
Points
Points
Points
Points
12 Cd-S @ All
32 Cd-S @ All
96 Cd-S @ All
72 Cd-S @ All
50 V - 450 H Points
50 V - 450 H Points
50 V - 450 H Points
50 V - 450 H Points
10 - 30% of the above
NIGHT
* Single center rear or combined dual rear (Optional)
MODAL EMERGENCY LIGHTING SYSTEM
RED
CLEAR
AMBER
RED
COLOR &
LOCATION
Front and
Front
Rear Center
Grille and Fender
MODE OF
Rear Corners
Upper Center
OPERATION
PRIMARY
ON
ON
ON
ON
"Clear the Right-of-Way"
SECONDARY
ON
OFF
ON
OFF
"Hazard-Vehicle Stopped on
Right-of-Way""
34
